Special Features

  • Reduced noise and vibrations.
  • Minimum frame gapping, low, angular deflection.
  • High rigidity frame and bolster.
  • High precision forming for longer dielife.
  • Hi-Torque pneumatically operated single disk combined clutch and brake unit.
  • Gear transmission runs in oil bath.
  • Wide slide and bolster area.

Frame, Bolster & Rigidity

Frame, Bolster & Rigidity

Highly rigid frame & wide point spacing The highly rigid frame, slide & bolster hold the frame gap opening, frame elongation & bed deflection to the absolute minimum. The wide point spacing enables the presses to with stand eccentric loads.

The highly rigid frame of the press is designed to ensure that there is a minimum level of angular deflection under stamping load - frame deflection & elongation. The thick bolster minimizes deflection which results in providing a sufficient margin for operations that require high accuracy.

Slide Counter Balance

Slide Counter Balance

Pneumatic counter balancers are provided to counter the weight of the slide and toolings, which help in taking up the bearing clearances and ease side adjustment, as well as smooth movement of the slide and effective braking.

Slide Guideways & 6-Point Gibs

Slide Guideways & 6-Point Gibs

The structure is bilaterally symmetrical and the six-face guideway provide full length support to slide to minimize left to right and front to back movement, as well as rotational tendency of the slide during operations resulting in prolonged die life.

The mechanism that ensure high precision. The high quality power shaft is employed to give outstanding torsional rigidity. Long 6 point gibs, ensure that accuracy is maintained for a very long time. Die life is also.

Lowest Overall Clearance

Lowest Overall Clearance

On the KAWA low clearance is achieved by accurately machined'rtorque transmitting parts, particularly the joints, connecting crank, connecting rod, ram screw and slide. The overall clearance is less than half of conventional presses which reduces break through and other stresses associated with punching.

All this results in : - Substantially prolonged die life. - Noise level is reduced to a minimum - High accuracy of points and torque-transmitting portions are easily maintained improving the durability of the press.
