Frame

The frame is of all steel construction, fabricated from Rolled steel plates with suitable cross ribbings. Presses upto 30T will be supplied with C.I. legs. proper alignment of the frame is ensured by machining.

Clutch

The clutch is of pin/rolling key-type. The clutch is rigid and well supported. The clutch gives continuous strokes for mass production.

Crank Shaft

Crank shaft is made of special alloy steel machined to close accuracy and fitted in bronze bushes for smooth working, longer life & accuracy.

Flywheel

Properly sized flywheel, is made of high grade cast iron, for storing and releasing adequate energy for the pressing operations, and properly balanced for smooth running.

Gears

Gear are of steel cast or fabricated. Gear teeth are generated by precision hobbing machine.

Table & fam

Table and fam are made pf high grade heavy duty cast iron & properly seasoned. They are perfectly aligned, to each other to obtain high accuracy & precision press operation.

Lubrication

An efficient shot lubrication system has been provided for lubricating the sliding surfaces and moving parts. The lubricant is applied by hand pump.

Inclining

Inclinable type presses are provided with inclining mechanism which can be easily det and locked in.

Mechanism

Position by spanners within minutes. the press is so designed that even in maximum inclined position, it is stable under heavy pressing load.
